Zhongshan Risheng Stripping Equipment Parts
Professional manufacturer of enameled wire stripping machines - paint removal machines - stripping consumables
1 / 2
| Machine Model | YSM-03018 New Generation 2 |
|---|---|
| Applicable wire diameter | 0．40-4．0mm |
| Machine Dimensions | 255X55mm |
| Operating Voltage | 220v/50Hz |
| Motor power | 25w |
| speed | 0-10000r/min |
| Machine Weight | 3．5kg |
| Optional accessories | Three-claw blade |
| Stripping length | 2－40mm |
| Brand | Risheng Hardware |
以上为标准机型数据，线径、电压及配件可按需定制，具体请联系客服确认。
YSM-03018 New 3rd Generation Enameled Wire Scraper | Enameled Wire Lacquer Remover. It is a compact and easy to use tabletop enameled wire scraping tool. Can be adjusted to adapt to various specifications of enameled wire, easy to apply, can quickly scrape off the enameled wire surface insulating film, paint clean, smooth surface. Its superior performance completely replaces traditional paint removal methods such as manual blade scraping, grinding wheel or sandpaper abrasion and chemical corrosion. It not only greatly improves work efficiency but also offers excellent solderability, making it the ideal enameled wire scraping equipment for coil manufacturing and repair industries such as motors, electrical appliances, instruments, transformers, electronics and home appliances, power tools. It integrates an electronic stepless regulator, motor and scraping blade, and uses a light, durable micro switch. It features fast scraping speed, high efficiency, simple operation, stable performance, low failure rate and a novel design. Suitable wire diameter 0.40-4.0mm (universal for all wire diameters, no blade replacement needed)
Specifications
Installation and Use
Extend the enameled wire into the center of the tool holder, press the start switch, and the motor will turn. Slowly pull the enameled wire out of the tool holder and the stripping is complete. According to the different wire diameter of the enameled wire, adjust the speed of the blade. The finer the wire diameter, the lower the speed needs to be, and the thicker the wire diameter, the faster the speed will be adjusted.
Zhongshan Risheng Hardware Products Co., Ltd. mainly focuses on the research and development, manufacturing, and sales of enameled wire scrapers, hand-held scrapers, electric scrapers, enameled wire scrapers, hand-held electric scrapers, scrapers, scrapers, scrapers, etc.
