Zhongshan Risheng Stripping Equipment Parts
Professional manufacturer of enameled wire stripping machines - paint removal machines - stripping consumables
1 / 5
| Machine Model | GD-550 |
|---|---|
| Applicable wire diameter | 0．30-4．0mm |
| Machine Dimensions | 255X55mm |
| Operating Voltage | 220v/50Hz |
| Motor power | 120w |
| speed | 0-2400r/min |
| Speed Adjustment | Stepless speed regulation |
| Optional accessories | Tungsten Alloy Blade |
| Stripping length | 2－50mm |
| Brand | Risheng Hardware |
以上为标准机型数据，线径、电压及配件可按需定制，具体请联系客服确认。
The GD-550 enameled wire paint removal machine | enameled wire stripping machine adopts the currently advanced Taiwanese electricstripped of paintTechnology, suitable for wire diameter: 0.3-4.0mm, can adjust the length of scraping paint, adapt to various specifications of enameled wire, easy to apply, can quickly scrap enameled wire insulating film, decontamination clean, smooth surface. Its superior performance completely replaces the traditional manual knife scraping, grinding wheel grinding paper, potion corrosion and other paint removal methods, which not only greatly improves the work efficiency, but also has strong weldability. It is an ideal enameled wire scraping equipment for coil manufacturing and repair industries such as motors, electrical appliances, meters, transformers, electronics, household appliances, power tools, etc. It collects electronic stepless governors, motors andPaint stripping bladeIntegrated with a lightweight and durable microswitch. It has the characteristics of fast scraping speed, high efficiency, simple operation, stable performance, low failure rate and novel and practical design. (Different wire diameters do not require any tools, within a few seconds, the twisted line can be quickly removed and cleaned, and the wire is constantly wired)
Specifications
Installation and Use
Start the machine switch, the motor will then rotate, and then push the enameled wire into the center of the tool holder to achieve the requiredstripped of paintAfter positioning, the stripping is completed by slowly pulling the enameled wire out of the tool holder. According to the different wire diameter of the enameled wire, adjust the speed of the blade. The finer the wire diameter, the lower the speed needs to be, and the thicker the wire diameter, the faster the speed will be adjusted.
Zhongshan Risheng Hardware Products Co., Ltd. is mainly engaged in the research and development, manufacturing, and sales of enameled wire de-lacquering machines, desktop de-lacquerizers, electric de-lacquerizers, enameled wire de-lacquerizers, tabletop electric de-lacquerizers, de-lacquerizers, de-lacquerizers, enameled wire de-lacquerizers, de-lacquerizers, and so on.
Related Products Enameled wire paint removal machine belt Interfaceless continuous enameled wire stripping machine belt Enameled wire paint removal blade | stripping blade Enameled wire paint removal machine fibre grinding wheel | stripping wire wheel Enameled wire paint removal blade | paint removal blade
Customers are welcome to sample test and paint stripping products customization!Welcome to sample test and peeling paint product customization ! Your browser does not support HTML5 video tags.
