GD-6C automatic enameled wire stripper (with speed control)

The GD-6C automatic enameled wire stripping machine adopts the current advanced electric paint scraping technology in Taiwan, which can adjust the length of the paint scraping and adapt to various specifications of the enameled wire. It is easy to apply, and can quickly scrape the insulating paint film of the enameled wire, decontaminate and clean, and the surface is smooth. Its superior performance completely replaces the traditional manual knife scraping, grinding wheel grinding paper, potion corrosion and other paint removal methods, which not only greatly improves the work efficiency, but also has strong weldability. It is an ideal enameled wire scraping equipment for coil manufacturing and repair industries such as motors, electrical appliances, meters, transformers, electronics, household appliances, power tools, etc. It integrates an electronic stepless governor, an electric motor and a paint scraper blade, and adopts a lightweight and durable microswitch. Features fast stripping speed, high efficiency, simple operation, stable performance, a low failure rate and a novel, practical design(With speed control efficiency is several times higher than ordinary)

Specifications

Installation and Use

Select the appropriate wire diameter, insert an enameled wire in the middle of the blade, rotate the blade by hand to adjust the blade so that the blade gently clamps the enameled wire, then pull the enameled wire out and lock the fixed 2 screws. After activating the switch and adjusting the speed according to the speed control switch to the appropriate speed, hold the coil part and then easily push the enameled wire into the high-speed rotating blade head until the preset paint stripping length is reached, and then carefully exit the enameled wire and the paint stripping work can be completed. If necessary, the caliber of the blade head can be adjusted by relaxing the same tightening chuck to control the desired paint stripping effect, because when the machine is started and the blade head rotates at a high speed, the insulating paint or oxide of the enameled wire is cut off, and the paint stripped enaminated wire has a bright and clean surface.

GD-6C automatic enameled wire stripping machine sets the required paint stripping length, you can loosen the fixing screw of the blade head, after the rotary blade head is loosened, you can see the limit thimble of the paint stripping length, through the fixing screw to adjust the limit thimble, you can set and control the paint stripping length of the enameled wire.
